Name: Truck Paint Room Bus Spray Booth with 2 Sets of 11KW Intake Fans and LPG Heating Source
Brand: Guangzhou Wintai Car Tools Co., Ltd.
SKU: WT15000
Price: 24,000.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Type: Spray Booths

Power: 39KW

External Size: 15150*6700*5000mm

Internal Size: 15000*5000*4550mm

Voltage: 110V/220V/ 380V

Disc Dia.: NM

No Load Speed: NM

Warranty: 1 Year

Color: Red,orange,white,blue

Heating Source: Diesel,gas,LPG,electricity

Suitable Vehicle: Bus,truck

Intake Fan: 2sets Of 11KW Fans

Exhaust Fan: 2sets Of 7.5KW Fans

Light: LED

Basement: Pits Or No Basement

Ceiling Filter: F5/EU5/600G

Floor Filter: Fiberglass

Exhaust Filter: Fiberglass

Highlight:

Paint Room Bus Spray Booth

Basic Infomation

Place of Origin: Guangdong, China

Brand Name: WINTAI

Model Number: WT15000

Payment & Shipping Terms

Gallery

Truck Paint Room Bus Spray Booth with 2 Sets of 11KW Intake Fans and LPG Heating Source

Product Description

Truck Paint Room Bus Spray Booth with 2 Sets of 11KW Intake Fans and LPG Heating Source

Product Overview

Professional truck and bus spray booth featuring advanced filtration systems, high-capacity ventilation, and efficient heating solutions for industrial painting applications.

Key Features

Wallboard Construction

Fire-retardant composite sandwich panels with 75mm EPS thickness (rock wool and PU optional). Features HDG colorful steel skin boards and high-quality galvanized steel roof panel.

Door System

4 front doors with aluminum bordure (4000×5000mm) and 2 emergency doors (650×1800mm each) for safety and accessibility.

Ventilation System

2 groups of 11KW intake fans (64,000m³/h total) with BELIMO 20N electric dampers and 2 groups of 7.5KW exhaust fans (40,000m³/h total).

Filtration System

Multi-layer filtering achieving 98% air cleanliness. Primary filter captures >10μm particles, ceiling filter captures >5μm particles, with green filters for paint and dust emission control.

Heating System

Original Italy RIELLO RG5S diesel burners (2 units, 520,000Kcal/h total) with stainless steel heat exchangers (85% efficiency) reaching maximum temperature of 80°C.

Lighting System

116 pieces of 18W LED lamps (900 Lux) with 72 ceiling lights and 44 side lights for optimal illumination.

Control System

Microcomputer control system with cabinet-type design for easy operation and maintenance.

Optional Features

Customizable sizes available
3D lift system (optional)
Air exhaust from sides or pit (optional)
Drive-through, rolling, or folding doors (optional)
Top-mounted air generation system (optional)

Technical Specifications

Type	Spray Booths
Power	39KW
External Size	15150×6700×5000mm
Internal Size	15000×5000×4550mm
Voltage	110V/220V/380V
Place of Origin	China, Guangdong
Brand Name	WINTAI
Model Number	WT15000
Warranty	1 year
Color Options	Red, Orange, White, Blue
Heating Source	Diesel, Gas, LPG, Electricity
Suitable Vehicle	Bus, Truck
Intake Fan	2 sets of 11KW fans
Exhaust Fan	2 sets of 7.5KW fans
Lighting	LED
Basement	Pits or no basement
Ceiling Filter	F5/EU5/600G
Floor Filter	Fiberglass
Exhaust Filter	Fiberglass
