Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment

1
MOQ
To be discussed
Price
Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment
Features Gallery Product Description Request A Quote
Features
Specifications
Mains Voltage: 3-phase/AC380V
Total Power: 34KW
Water Supply: DN25mm/Waterflow Rate≥200L/min
Air Pressure: 0.75-0.9Mpa/Airflow Rate≥0.1m³/min
Water/electricity Consumptio: 150L/Car, 0.6kw/Car
Shampoo Consumption: 7ml/Car
Water Wax Consumption: 12ml/Car
Overall Dimensions: 10470x3700mm
Available Size For Car: 5300x2200x2100mm
Brushes: 9
Highlight:

9 brushes Automatic Car Washing Machine

,

High Pressure Automatic Car Washing Machine

,

High Quality Automatic Car Washing Machine
Basic Infomation
Place of Origin: China
Brand Name: WINTAI
Certification: ce
Model Number: WT-690
Payment & Shipping Terms
Packaging Details: Standard export packaging
Delivery Time: 25
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 100
Product Description
WT-690 Automatic Tunnel Car Wash Machine Machine.
1. Technology originally from Japan.
2. Stable motors from Japan guarantee reliable function.
3. Inclinable side brush strengthens cleaning ability around the car.
4. Car shape imitating dry system.
5. Countinously washing car after car
6. Two function(Car wash, Inspection) on operation panel
7. Save cost of hiring 3-4 employee.
8. Long durable time: More than 10 years
9. Fault self-detect function


Specifications:

Overall dimensions 9500x3800x3440mm Mains voltage 3-phase/AC380V
Assembling range 11600x3800mm Water supply DN25mm/Waterflow rate≥200L/min
Moving range 10470x3700mm Air pressure 0.75-0.9Mpa/Airflow rate≥0.1m³/min
Available size for car 10470x3700mm Air pressure 0.75-0.9Mpa/Airflow rate≥0.1m³/min
Available car to wash car/jeep/coach within 10seats Water/electricity consumptio 150L/Car, 6kw/Car
Washing time 1'30"/Car Shampoo consumption 7ml/Car
Car wash capacity 45-55cars/hour Water wax consumption 12ml/Car



Accessories and Parts List:
Standard parts Quantity Remarks Standard parts Quantity Remarks
Shampoo sprinkling system 1 set available Conveyer motor   FUKUTA
Water wax sprinkling system 1 set available gear motor 1 TKA
Shape imitating dry system 1 set available Brush motor   TSUBAKI
High pressure water device 1 set available Photoelectric sensor 6 Pair Banner
Vehicle bottom wash 1 set optional Frequency converter   Toshiba
Brushes 9 available Fan electric motor 4 ABB
Intelligent equipment data   available Magnetic valve   CKD/SMC/Koganei
Fault self-detection   available IP67 waterproof electric motor 7sets SKK
Frame 1 set hot-dip galvanized Contactor   Mitsubishi
Electronic control system 1 set MK cabinet Hot protective relay   Mitsubishi
Conveyer system 1 set available



Washing Procedure
Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment 0
Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment 1
Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment 2
Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment 3
Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment 4
Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment 5
Main Compenet Part
Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment 6
Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment 7Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment 8
Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment 9
Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment 10Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment 11
Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment 12



Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment 13
Tunnel Type Automatic Car Washing Machine With 9 Brushes EVA Brushes Automated Car Wash Equipment 14
