11 Brushes Fully Automatic Tunnel Car Wash Machine EVA Brushes High Pressure Automated Car Wash Equipment

1
MOQ
To be discussed
Price
11 Brushes Fully Automatic Tunnel Car Wash Machine EVA Brushes High Pressure Automated Car Wash Equipment
Features Gallery Product Description Request A Quote
Features
Specifications
Mains Voltage: 3-phase/AC380V
Water Supply: DN25mm/Waterflow Rate≥200L/min
Air Pressure: 0.75-0.9Mpa/Airflow Rate≥0.1m³/min
Water/electricity Consumptio: 180L/Car, 0.6kw/Car
Shampoo Consumption: 10ml/Car
Water Wax Consumption: 12ml/Car
Assembling Range: 16000x3800mm
Available Size For Car: 5200x2150x2200mm
Overall Dimensions: 15800x3800x3440mm
Highlight:

High Quality Automatic Car Wash Machine

,

High Pressure Automatic Car Wash Machine

,

11 brushes Automatic Car Wash Machine
Basic Infomation
Place of Origin: China
Brand Name: WINTAI
Certification: ce
Model Number: WT-692
Payment & Shipping Terms
Packaging Details: Standard export packaging
Delivery Time: 25
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 100
Product Description
11 Brushes Fully Automatic Tunnel Car Wash Machine - EVA Brushes - High Pressure Automated Car Wash Equipment
WT-692 Automatic Tunnel Car Wash Machine
  • High pressure water pre-washing and chassis sprinkling
  • Shampoo (Foams) sprinkling and wax washing systems
  • Nine brushes with foam material and lifelong warranty
  • Three blowers dry the car body completely and precisely
  • Two wheel wash brushes to wash the tires
  • PLC control system & humanized operate panel
  • Intelligent avoidance system to wash all kinds of car types
  • Main technology and machine design from Japan
  • Electroplated conveyor equipped with the tire corrector device
  • Hot-dip galvanized steel frame keep the whole machine anti-rust
  • Motors, electrical apparatus, pumps all imported from abroad
  • With one years warranty and lifelong maintenance service
  • Technician to customer site installation and maintenance training
Specifications
Overall dimensions 15800x3800x3440mm Mains voltage 3-phase/AC380V
Assembling range 16000x3800mm Water supply DN25mm/Waterflow rate≥200L/min
Moving range 35000x5800mm Air pressure 0.75-0.9Mpa/Airflow rate≥0.1m³/min
Available size for car 5200x2150x2200mm Water/electricity consumption 180L/Car, 0.6kw/Car
Available car to wash car/jeep/coach within 10 seats Shampoo consumption 10ml/Car
Washing time 1'12"/car Water wax consumption 12ml/Car
Car wash capacity 45-50 cars/hour
Washing Procedure
Automatic tunnel car wash machine washing procedure step 1 Automatic tunnel car wash machine washing procedure step 2 Automatic tunnel car wash machine washing procedure step 3 Automatic tunnel car wash machine washing procedure step 4 Automatic tunnel car wash machine washing procedure step 5 Automatic tunnel car wash machine washing procedure step 6
Main Component Parts
Automatic tunnel car wash machine main component part 1 Automatic tunnel car wash machine main component part 2 Automatic tunnel car wash machine main component part 3 Automatic tunnel car wash machine main component part 4 Automatic tunnel car wash machine main component part 5 Automatic tunnel car wash machine main component part 6 Automatic tunnel car wash machine main component part 7
