Home/Products/Touchless Car Washer/360 degree rotating arms Automatic Car Wash Machine Intelligent Automatic Brushless Car Wash Car Wash Machine Fully Automatic
360 degree rotating arms Automatic Car Wash Machine Intelligent Automatic Brushless Car Wash Car Wash Machine Fully Automatic
360 degree rotating arms Automatic Car Wash Machine Intelligent Automatic Brushless Car Wash Car Wash Machine Fully Automatic
Product Description
Touch free car washing machine automatic Laserwash
This is a headache-free machine which can make your business better. You don't need much energy to maintain it as we consider a lot for the quality of each component. Total weight 2.8 tons and 11 cubic meters.
Keywords:
Touch free car washing machine
self-service car washing machine
Touchless car washing machine
brushless car washing machine
Optional:
Waste water recycling system
Self-service payment system
colorful lights system
Laser pipe cutting machine
All the tube and frame firstly cutting by the laser machine with high precision.
Laser board cutting machine
All the steel board will be cutting by the laser machine with high precision.
CNC bending machine
To make bend the frame directly without any welding point, can the frame more stable.
Hot-dip Galvanized frame without welding.
The frame adopts laser high-precision cutting, CNC bending, 304 stainless steel high-strength screw fixation, the overall operation precision is higher than the welding frame precision, more stable and safe.
The frame steel adopts Q235 international standard profile, the thickness is 4mm, the surface is treated by pickling, phosphating and hot dip galvanizing, SGS salt spray test grade report is grade 10.
Special Feature:
Users can set chemical consumption automatically on touch screen according to the dirty degree of vehicles.
Wasing Mode:
1.Fine Mode (5 minutes/car): start--chassis/wheel rim flushing--Colorful high foam detergent spraying--High Pressure Car Body Flushing--shampoo spraying--High pressure car body flushing--Wax Spraying---Drying--End
2.Fast Mode (2 minutes/car): start--chassis/wheel rim flushing--Colorful high foam detergent spraying--High Pressure Car Body Flushing--Drying--End
Item
Parameters
Function
Remark
Machine Size(L*W*H)
3670mm*1330mm*1300mm
Self-parking and detecting system
√
Pump Size(L*W*H)
1280mm*740mm*600mm
Digital anti-collision system
√
Chemical station size(L*W*H)
1160mm*470mm*1350mm
All degree rotary high pressure flushing
√
Max Vehicle Suitable
6000*2500*2080mm
Chassis flushing
√
Installation(L)-Frame Length
7500mm~8000mm
Detergent spraying
√
Installation(W)
3350mm~3686mm
Colorful/high foam detergent spraying
√
Installation(H)
3300mm-3400mm
Wax spraying system
√
Total Weight/volume
≥3300kgs/≥8.5m³
Built-in automatic drying system
√
Power Requirement
380V/25KW or other voltage
LED indication light guide system
√
Air Switch
100A
Operation permission setting function
√
Total Power
13KW/24.5KW
Self-service payment system
√
Water Pump Motor Power
18.5KW/pressure 100Bar,100-100 Bar Adjustable,Simens
Voice Prompts function
√
Fan Motor Power
5.5KW/set x4sets
Car washing counting function
√
Horizontal Motor Power
0.55KW asynchronous frequency conversion speed regulation
Antifreeze system
√
Cross Motor Power
1KW digital servo motor
Oil-free system
√
Rotation motor Power
1KW digital servo motor
Equal pressure anti-blocking nozzle
√
Chemical Proportion Motor Power
0.37KW
Safe alarm system
√
Central Processing unit PLC
Industrial intelligent digital control system
Automatic Standby function
√
Drive system
variable frequency speed control+digital servo driver
Inspection system
Intelligent three-dimensional detection system
Running speed
27 seconds/360 degree one circle
Self-service payment system
.
Water consumption
65-200L/car
Colorful Lights(like above right picture)
.
Electricity consumption
0.4-1KW.H/car
Water Recycle System
.
√ Standard . Optional
Optional : sewage purification and recycling system
