Features Gallery Product Description Request A Quote

Features

Specifications

Color: Blue

Material: Metal

Fan Motor Power: 4KW/set X3sets

Water Pump Motor Power: 100Bar Working Pressure, Max. 120Bar

Total Power: 16KW

Air Switch: 100A

Power Requirement: AC380V/50Hz/3Ph

Total Weight/volume: ≥2100kgs/≥7.5cube

Machine Size(L*W*H): L*W*H=7500*3500*3200mm

Electricity Consumption: Approx. 0.75KW/car

Water Consumption: Approx. 150L/car

Max Vehicle Suitable: L*W*H=5600*2100*2080mm

Shampoo Consumption: Approx. 40ml/car

Foam Consumption: Approx. 40ml/car

Water Wax Consumption: Approx. 80ml/car

Magic Color Bubble Consumption: Approx. 80ml/car

Time Consumption: 120s/car

Highlight:

Full Automatic Touchless Car Washer

Single Arm Touchless Car Washer

16KW Touchless Car Wash Machine

Basic Infomation

Place of Origin: Guangdong, China

Brand Name: WinTai

Certification: CE

Model Number: T12

Payment & Shipping Terms

Packaging Details: Standard export packaging

Delivery Time: 25

Payment Terms: L/C, D/A, D/P, T/T

Supply Ability: 500 Set/Sets per Month

Gallery

Full Automatic Touchless Car Washer With Single Arm Total Power 16KW

Product Description

Full Automatic Touchless Car Washer With Single Arm Total Power 16KW

Product Overview

Full automatic brushless car washing machine single arm automatic car wash machine with advanced touch screen controls for automated chemical consumption based on vehicle dirt level.

Technical Specifications

Item	Parameters	Function	Remark
Installation Size (LWH)	750035003200mm (24.6ft 11.48ft 10.5ft)	Chassis wash function	Yes
Max. Car Size	560021002080mm (18.37ft 6.89ft 6.82ft)	360-degree high pressure water wash	Yes
Shampoo Consumption	Approx. 40ml/car	Foam function	Yes
Foam Consumption	Approx. 40ml/car	All degree rotary high pressure flushing	Yes
Water Wax Consumption	Approx. 80ml/car	Shampoo function	Yes
Magic color bubble consumption	Approx. 80ml/car	Wax rain	Yes
Water Consumption	Approx. 150L/car	Built in 4Pcs * 3KW Air dry	Yes
Electricity Consumption	Approx. 0.75KWH/car	Self-guided parking system	Yes
Time Consumption	4.5min/car, 8 hours 100 cars	Vehicle length detection	Yes
Air Switch	100A air switch	LED indication light guide system	Yes
Power Supply Requirements	AC380V/50Hz/3Ph/16KW, 14smm copper cable	Operation permission setting function	Yes
Water Pump Motor Power	Germany PINF Pump 15KW/100Bar working pressure, Max. 120Bar	Self-service payment system	Yes
Water Pump Motor Power	18.5KW/pressure 130Bar, 10-130Bar Adjustable, Simens	Voice Prompts function	Yes
Fan Motor Power	Built in 4 pcs 3KW blowers total 12KW	Vehicle width detection	Yes
Remote Control	Remote Control	Automatically adjust	Yes
Central Processing Unit PLC	Industrial intelligent digital control system	LED alert system	Yes
Drive System	Variable frequency speed control + digital driver	Washing quantity counting function	Yes
Detection System	Intelligent three-dimensional detection system	Fault self-test function	Yes
Central Processing unit PLC	Industrial intelligent digital control system	Wireless remote control system	Yes
Drive system	Variable frequency speed control + digital servo driver	Galvanized frame	Yes
Sensing System	Ultrasound + Absolute value of the digital encoder, 1 sensors

Product Gallery

Manufacturer Profile

Guangzhou Wintai Cartools Co., Ltd is a professional manufacturer of car washing machine equipment established in 2013, integrating R&D, production, sales and service. WINTAI focuses on high-end car washing machine manufacturing and design, and strives to provide consumers with higher quality car washing machine equipment.

The workshop is located in Xi'an and has an export office in Guangzhou. Xi'an is an international transportation hub with strategic advantages for export transportation.

WINTAI specializes in the research and development of fully automatic computer car wash equipment. Based on the absorption of advanced technology from the same industry in the world, WINTAI adopts a unique design concept and combines the domestic car wash market conditions. After years of continuous research, testing and testing, and further innovation, we have developed a new generation of stable T series surrounding high-pressure non-contact wipe-free automatic computer car wash system. It's cost-effective, reliable and with stable performance.

Among them, T9 and WT-390 are the leading products of our company. Both T9 and WT-390 have self-service payment systems. This is a further elimination of labor compared to the traditional car wash industry, and to make up for the short-term business hours. 24h all-day business can solve the problem of car owners car wash time, but also create more benefits for investors.

WT-390 is more inclined to meet the basic needs of the current market. It is a suitable choice for the car wash industry or the general washing station. The T9 has a larger flushing pressure, the maximum flushing pressure can reach 130bar. It's with 4pcs of 5.5kw fans, and the surrounding flushing speed reaches 27 seconds in 360 degrees around the car, its washing speed is faster. Secondly T9 has more washing modes compared to the general car washing machine. The car owner can choose different modes according to actual needs.

In short, both T9 and WT-390 can meet export requirements. We also export these products to Malaysia, Armenia, Kazakhstan, Russia, Nigeria and the vast European countries.
