Features

Specifications

Type: Other

Color: Blue

Material: Metal

Fan Motor Power: 5.5KW/set X4sets

Water Pump Motor Power: 18.5KW/pressure 130Bar,10-130Bar Adjustable,Simens

Total Power: 13KW/24.5KW

Air Switch: 100A

Power Requirement: 380V/25KW Or Other Voltage

Total Weight/volume: ≥3300kgs/≥10cube

Machine Size(L*W*H): 3670mm*1330mm*1300mm

Pump Size(L*W*H): 1280mm*740mm*600mm

Chemical Station Size(L*W*H): 1160mm*470mm*1350mm

Max Vehicle Suitable: 6000*2500*2080mm

Port: Guanbgzhou/Qingdao

Horizontal Motor Power: 0.55KW Asynchronous Frequency Conversion Speed Regulation

Cross Motor Power: 1KW Digital Servo Motor

Rotation Motor Power: 1KW Digital Servo Motor

Chemical Proportion Motor Power: 0.37KW

Running Speed: 27 Seconds/360 Degree One Circle

Water Consumption: 65-200L/car

Electricity Consumption: 0.4-1KW.H/car

Highlight:

Metal Touchless Automatic Car Wash

High Pressure Touchless Automatic Car Wash

Metal Touch Free Automatic Car Wash

Basic Infomation

Place of Origin: Guangdong, China

Brand Name: WinTai

Certification: CE

Model Number: T9

Payment & Shipping Terms

Packaging Details: Standard export packaging

Delivery Time: 25

Payment Terms: D/A, L/C, D/P, T/T

Supply Ability: 500 Set/Sets per Month

Gallery

T9 Metal Touchless Automatic Car Wash High Pressure For Vehicles Cleaning

Product Description

T9 No brush type Automatic car wash machine touchless car washing machine car automatic car washer

Special Feature

Users can set chemical consumption automatically on touch screen according to the dirty degree of vehicles.

Wasing Mode

Fine Mode (5 minutes/car): start--chassis/wheel rim flushing--Colorful high foam detergent spraying--High Pressure Car Body Flushing--Low foam detergent spraying--High pressure car body flushing--Wax Spraying--Wax Rain--Drying

Fast Mode (2 minutes/car): start--chassis/wheel rim flushing--Colorful high foam detergent spraying--High Pressure Car Body Flushing--Wax Spraying--Wax Rain--Drying

The frame adopts laser high-precision cutting, CNC bending, 304 stainless steel high-strength screw fixation, the overall operation precision is higher than the welding frame precision, more stable and safe.

The frame steel adopts Q235 international standard profile, the thickness is 4mm, the surface is treated by pickling, phosphating and hot dip galvanizing, SGS salt spray test grade report is grade 10

Item	Parameters	Function	Remark
Machine Size(LWH)	3670mm1330mm1300mm	Self-parking and detecting system	yes
Pump Size(LWH)	1280mm740mm600mm	Digital anti-collision system	yes
Chemical station size(LWH)	1160mm470mm1350mm	All degree rotary high pressure flushing	yes
Max Vehicle Suitable	600025002080mm	Chassis flushing	yes
Installation(L)-Frame Length	7500mm~8000mm	Detergent spraying	yes
Installation(W)	3350mm~3686mm	Colorful/high foam detergent spraying	yes
Installation(H)	3300mm-3400mm	Wax spraying system	yes
Total Weight/volume	≥3300kgs/≥8.5m³	Built-in automatic drying system	yes
Power Requirement	380V/25KW or other voltage	LED indication light guide system	yes
Air Switch	100A	Operation permission setting function	yes
Total Power	13KW/24.5KW	Self-service payment system	yes
Water Pump Motor Power	18.5KW/pressure 130Bar,10-130Bar Adjustable,Simens	Voice Prompts function	yes
Fan Motor Power	5.5KW/set x4sets	Car washing counting function	yes
Horizontal Motor Power	0.55KW asynchronous frequency conversion speed regulation	Antifreeze system	yes
Cross Motor Power	1KW digital servo motor	Oil-free system	yes
Rotation motor Power	1KW digital servo motor	Equal pressure anti-blocking nozzle	yes
Chemical Proportion Motor Power	0.37KW	Safe alarm system	yes
Central Processing unit PLC	Industrial intelligent digital control system	Automatic Standby function	yes
Drive system	variable frequency speed control+digital servo driver
Inspection system	Intelligent three-dimensional detection system
Running speed	27 seconds/360 degree one circle
Water consumption	65-200L/car	Colorful Lights(like above right picture)	Optional
Electricity consumption	0.4-1KW.H/car	Water Recycle System	Optional

T9 Metal Touchless Automatic Car Wash High Pressure For Vehicles Cleaning 0

T9 Metal Touchless Automatic Car Wash High Pressure For Vehicles Cleaning 1

T9 Metal Touchless Automatic Car Wash High Pressure For Vehicles Cleaning 2

T9 Metal Touchless Automatic Car Wash High Pressure For Vehicles Cleaning 3

T9 Metal Touchless Automatic Car Wash High Pressure For Vehicles Cleaning 4

T9 Metal Touchless Automatic Car Wash High Pressure For Vehicles Cleaning 5

T9 Metal Touchless Automatic Car Wash High Pressure For Vehicles Cleaning 6

T9 Metal Touchless Automatic Car Wash High Pressure For Vehicles Cleaning 7

T9 Metal Touchless Automatic Car Wash High Pressure For Vehicles Cleaning 8

T9 Metal Touchless Automatic Car Wash High Pressure For Vehicles Cleaning 9

T9 Metal Touchless Automatic Car Wash High Pressure For Vehicles Cleaning 10
