Flatbed cable chain Automated Car Wash Equipment with 14 brushes Auto Car Wash Machine with 6 dyers

1
MOQ
To be discussed
Price
Flatbed cable chain Automated Car Wash Equipment with 14 brushes Auto Car Wash Machine with 6 dyers
Features Gallery Product Description Request A Quote
Features
Specifications
Device Size: 25×4×3.5m
Power Requirem-ent: AC380V50Hz (5-wire System)
Flatness Of The Ground: Error ≤ 10mm
Car Wash Size: 5.2m × 2.15m × 2.1m (wheelbase ≤3.2m)
Water Consumption Per Vehilce: 120 Liters Per Vehicle
Electricity Consumption Per Vehicle: 1.1 KWh Per Vehicle
Shampoo Consumption: 20-40ml Per Vehicle
Water-wax Consumption Per Vehicle: 30ml Per Vehicle
High Pressure Water Pump: HP Italy
Highlight:

flatbed cable chain car wash machine

,

automatic car wash equipment with brushes

,

auto car wash machine with dryers
Basic Infomation
Place of Origin: Guangzhou
Brand Name: WINTAI
Model Number: S9
Payment & Shipping Terms
Packaging Details: Standard export packaging
Delivery Time: 25days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 100 sets/month
Product Description
14-Brush Flatbed Tunnel-Type Car Wash Machine
Maximize efficiency with our fully automatic car wash system capable of cleaning four vehicles simultaneously. This industrial-grade tunnel-type machine delivers professional cleaning results with advanced automation and robust construction.
Flatbed cable chain Automated Car Wash Equipment with 14 brushes Auto Car Wash Machine with 6 dyers 0 Flatbed cable chain Automated Car Wash Equipment with 14 brushes Auto Car Wash Machine with 6 dyers 1 Flatbed cable chain Automated Car Wash Equipment with 14 brushes Auto Car Wash Machine with 6 dyers 2 Flatbed cable chain Automated Car Wash Equipment with 14 brushes Auto Car Wash Machine with 6 dyers 3
Technical Specifications
Model S9
Equipment Dimensions 25m × 4m × 3.5m (Length × Width × Height)
Installation Area 25,000mm long × 4,000mm wide
Power Requirements AC380V 50Hz (5-wire system)
Water Requirements Pipe diameter DN25, flow rate ≥200 L/min
Air Source Requirements Pressure 0.75-0.9Mpa, Flow rate ≥ 0.1m³/min
Ground Flatness Error ≤ 10mm
Vehicle Compatibility Cars, Jeeps, vans with less than 10 seats
Car Wash Dimensions 5.2m × 2.15m × 2.1m (wheelbase ≤3.2m)
Processing Capacity 50-60 vehicles per hour
Brush Configuration
Small Vertical Brush: 4 units
Large Vertical Brush: 4 units
Top Brush: 1 unit
Hub Brush: 2 units
Polishing Brush: 3 units
System Features
Frame Construction
Hot-dip galvanized external frame for superior corrosion resistance and durability
Chassis Flushing
Comprehensive undercarriage cleaning system
High Pressure Pre-flushing
140kg pressure motor pump system for effective pre-cleaning
Foam System
High-bubble foam application for thorough cleaning
Colorful Waterfall
Aesthetic and functional rinse system
Wax Spray
Integrated protective coating application
Air Drying System
6 high-power fans (4 top fans and 2 side fans) for complete drying
Entry Guide Platform
Precision vehicle alignment system
Drive System
Frequency conversion speed control with special thickened bearing and large ball drive chain
