1850mm Height 2 Post Auto Lift 380V Safety Operation With 5 Tons Capacity

1
MOQ
us$1550/set-us$1800/set
Price
1850mm Height 2 Post Auto Lift 380V Safety Operation With 5 Tons Capacity
Features Gallery Product Description Request A Quote
Features
Specifications
Lifting Capacity: 5.0T
Min Height: 85mm
Lifting Height: 1850mm
Rise Time: 50s
Descending Time: 30s
Motor Power: 2.2KW
Voltage: 220V/380V
Inner Width: 3000mm
Total Height: 3900mm
Total Width: 3560mm
Highlight:

5 Tons 2 Post Auto Lift

,

1850mm Height 2 Post Auto Lift

,

5 Tons Two Post Car Hoist

Basic Infomation
Place of Origin: China
Brand Name: WINTAI
Certification: CE
Model Number: 250L
Payment & Shipping Terms
Packaging Details: Standard export packaging
Delivery Time: 15
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 1000 sets/month
Product Description
1850mm Height 2 Post Auto Lift 380V Safety Operation With 5 Tons Capacity
Product Overview

This professional two-post car lift with 5-ton capacity is engineered for automotive service centers and repair shops, featuring advanced safety systems and robust construction for reliable performance.

Key Features
  • Oil cylinder parts manufactured using automatic high-speed CNC lathe for superior finish and concentricity
  • Japanese oil sealing elements with overload protection and international brand oil pipes
  • Direct driven by twin cylinders with safety steel wire synchronization
  • Polymer wear-resistance sliders for enhanced durability
  • Single side control with dual-side unlock safety system
  • Arm locks with tooth type ratchet mechanism for secure operation
  • Gantry design with no floor obstruction for maximum workspace
  • Roof protection safety device with automatic arm lock via built-in ratchet tooth
  • Shot blasting and high-temperature baking powder coated surface finish
  • CE certified with 7.5T static test and 5.7T dynamic test compliance
Technical Specifications
Specification Value
Design Two Post
Type Double Cylinder Hydraulic Lift
Lifting Capacity 5.0T
Place of Origin China, Guangdong
Brand Name WinTai
Model Number 250L
Warranty 1 Year
Minimum Height 85mm
Lifting Height 1850mm
Rise Time 50s
Descending Time 30s
Motor Power 2.2KW
Voltage 220V/380V
Total Height 3900mm
Inner Width 3000mm
Total Width 3560mm
Safety Certified: This two-post auto lift meets rigorous safety standards with CE certification, ensuring reliable performance for professional automotive applications.
