Features Gallery Product Description Request A Quote

Features

Specifications

Electricity Requirements: 380V/18.5Kw/50Hz

Installation Dimensions: 8000*3700*3400(mm)

Maximum Car Wash Size: 6000*2500*2050(mm)

Water Pump Motor(kw): 380V/18.5kw

Flushing Pressure: 80-120kg

Power Consumption（kWh）: 0.5-0.8/per

Water Consumption（L）: 100-200L

Material: 304 Stainless Steel

Rinse The Car Body Once: 2 8 S

Color: Customizable

Logo: Customizable

Highlight:

360 Car Wash Water Reclamation System

Flushing 360 Car Wash Reclamation

120 Bar 360 Car Wash Reclamation

Basic Infomation

Place of Origin: China

Brand Name: WINTAI

Certification: CE

Model Number: KP

Payment & Shipping Terms

Packaging Details: Standard export packaging

Delivery Time: 25

Payment Terms: L/C, D/A, D/P, T/T

Supply Ability: 100 sets/month

Gallery

360 Car Wash Water Reclamation System With Water Flushing Pressure 120 Bar Touchless Car Wash Equipment

Product Description

360 Car Wash Water Reclamation System With Water Flushing Pressure 120 Bar Touchless Car Wash Equipment

Product Overview

Built-in 360 Degree Rotating Arms

CAE computer aided simulation design ensures optimal nozzle placement and angle to prevent water hedging and maintain cleaning effectiveness
Intelligent distance calculation with safety and collision prevention functions
Equalized pressure, consistent distance, and uniform speed washing method
Complete 360° coverage for high pressure pre-wash, shampoo application, wax coating, and final drying
Enhanced rotation speed improved from one minute to just 30 seconds per rotation

Washing Modes

Fine Mode (5 minutes/car): Start → Chassis/Wheel Rim Flushing → Colorful High Foam Detergent Spraying → High Pressure Car Body Flushing → Low Foam Detergent Spraying → High Pressure Car Body Flushing → Wax Spraying → Wax Rain → Drying

Fast Mode (2 minutes/car): Start → Chassis/Wheel Rim Flushing → Colorful High Foam Detergent Spraying → High Pressure Car Body Flushing → Wax Spraying → Wax Rain → Drying

Technical Specifications

Product Name/Model	KP360 Intelligent Version
Three Phase Electricity/Overall Power	380V/55Kw
Power Requirements	380V/22Kw/50Hz
Installation Requirements	8000×3800×3400 mm
Maximum Car Wash Size	6000×2500×2050 mm
Installation Costs	Free Installation Guidance
Hanging Rail Length	8000 mm
Overall Weight/Volume	2650 kg / 13 m³
Central Processing Unit	Embedded Central Processing Unit Industrial Control
360 Degree Rotary Flushing	304 Stainless Steel Rotating Arm
Main Water Pump Motor/Power	380V/18.5 kW
Fan Motor/Power	5.5 kW × 4 or 5.5 kW × 6
High Pressure Flushing Pressure	60-120 kg
Rinse Car Body Once	28 S
Car Wash Time	Quick Washing: 2 min / Fine Washing: 5 min
Liquid Consumption	Metering Pump / 20-50 ml
Power Consumption	0.5-0.8 kWh per wash
Water Consumption	100-200 L per wash
