Do you need a car wash machine with six dryers?
Built-in 360 degree rotating arms:
1. CAE computer aided simulation design, reasonable placement of nozzle angle and position, to avoid water hedging to weaken the cleaning effect.
2. Intelligent distance calculation, safety and collision prevention function. Equalize pressure, equalize distance and uniform speed washing way.
3.High pressure water pre-wash, shampoos, waxing coating with 360 degree coverage, and finally drying.
Special Feature
Users can set chemical consumption automatically on touch screen according to the dirty degree of vehicles.
Wasing Mode
Fine Mode (5 minutes/car): start--chassis/wheel rim flushing--Colorful high foam detergent spraying--High Pressure Car Body Flushing--
Low foam detergent spraying--High pressure car body flushing--Wax Spraying--Wax Rain--Drying
Fast Mode (2 minutes/car): start--chassis/wheel rim flushing--Colorful high foam detergent spraying--High Pressure Car Body Flushing--
Wax Spraying--Wax Rain--Drying
Model | FS360-S |
Three phase electricity/overall power | 380V/50Kw |
Power requirements(kw) | 380V/33Kw/50Hz |
Installation requirements(mm) | 7000*3800*3200 |
Maximum car wash size(mm) | 5600*2500*2050 |
Hanging rail length (mm) | 7000mm |
Overall weight/volume | 2200kg/12m³ |
360 degree rotary flushing | 304 stainless steel rotating arm |
Main water pump motor/power (kW) | 380V/15kw |
Fan motor/power (kW) | 5.5kw*6 |
High pressure flushing pressure | 60-100kg |
Rinse the car body once | 2 8 S |
Liquid consumption(ml) | 20-50ml |
Power consumption(kWh) | 0.3-0.8/per |
Water consumption(L) | 80-150L |
